XGJ-6
type automatic inline screw capping machine by Shanghai Jiacheng company
recently improved capping machine.
Characteristic：
1. electromagnetic vibration sorting system, accurate screening
cap, more accurate and quick feed cap.
2.. The
operation space of the cap feeding track is large. It is controlled by the
regulating plate and the gate. It can be continuously supplied caps, complete
automatic production, save time and improve efficiency.
3.,
continuous split the bottle operation, free adjustment screw capping speed.
4.,
imported motor as the driving force of the screw cap, when reach torque will be
automatic brake, do not hurt the bottle cap, adjust the pressure level to determine
the bottle tightness.
5.,
torque size can be adjusted separately, you can freely adjust the tightness of
the screw cap.
6.,
change the packaging specifications, do not replace parts, only a simple
adjustment can be, easy to operate and easy maintenance.
Principle:
1, working voltage: 220V/50HZ - 60HZ
2, rated
power: 1500W
3,
production capacity: 60-100 bottles / min.
4,
bottle cap size: 15-70 mm
5, the
bottle diameter: 140 mm Phi Phi 25-
6, bottle
height: 38-300 mm
7,
exterior size: 1000*700*1600MM
8, net
weight: 250kg
